4ch 4in1 5mp Dvr Hd 2mp Cctv Security Camera 24ir Dome System

Description

High End 4CH 5-in-1 High Definition Full HD 5MP DVR With HD 2MP 4pcs Dome Camera System

DVR Feature

• 4 CH TVI / AHD / CVI / 960H video input, 1CH HD IP video input
• Recording: 15fps/CH 2M (for TVI / AHD / CVI), 15fps/CH  2MP (for IPC)
• Playback: 4CH simultaneously playback; HDMI 5MPP output
• Backup: USB, IE, CMS; support multi-file, file cutting when backup
• Pentaplex: live, record, playback, backup and remote operation
• Titanium OS
• DHCP, DDNS, PPPoE Network protocol, IE browse and CMS supported
• Dual stream technology; Multi-user online simultaneously
• Support PTZ preset and auto cruise, up to 128 presets and 8 cruises
• Cell phone: iPhone, Android
• Complete SDK function, easy to integrate with other applications
• Max HDD: 1 x HDD

 Specification

Video & Audio

Video Input

4 x BNC (HD TVI / HD AHD / HD CVI / 960H)

IPC Input

1 x IP Camera

Video Output

HDMI/VGA/CVBS(SPOT)

Audio In

4 x RCA

Audio Out

1 x RCA

Recording

Recording Resolution

 HD 5MP

Frame Rate (fps)

15fps/CH 1080P,

Frame Rate (IPC)

15fps/CH  2MP

Bit Rate

1M ~ 6Mbps

Encode

VBR/CBR

Record Mode

Manual, Timer, Motion

Quality

6 Level

File Manage

Lock, Unlock, Reserving Time

Playback

Playback

4CH

Search Mode

Time, Motion, Single, or Multi-Channel

Auxiliary Interface

RS485

1 x RS485, Connect to PTZ or keyboard

USB

2 x USB2.0, one for mouse & one for backup

Alarm

Alarm In

4CH

Alarm Out

1CH

Trigger Events

Record, PTZ Move, E-Mail, etc.

Mode

Motion, Video Loss

Network

Ethernet

RJ 45

Protocol

TCP/IP, UDP, DHCP, DNS, PPPoE, DDNS

User Access

10 Users online, dual stream

Storage

Internal HDD

1 x SATA (Up to 6TB)

External HDD

N/A

General

Power Supply

DC 12V

Power Consumption

? 5W ( without HDD )

Working Environment

14? ~ 122? (-10? ~ 50?), 10%~90% (Humidity)

Dimensions

11.8" x 10.6" x 2.2" (WxDxH) / 300 x 270 x 55mm

Camera Features

High Definition 1080P 2MP  HD 4-in-1 1/3" Sony CMOS, 3-axis 3.6mm Wide Angle View Lens. Dome Camera. 24 IR LEDs. Super Low 0 Lux Minimum Illumination. Perfect For Your Business or Restaurant.

• 1/3" Sony CMOS CCD
• IR-CUT for Night
• System of Signal  NTSC
• 4-in-1 HD 2MP
• Aluminum Housing
• Wide Angle View Lens

 Image Sensor

1/3" SONY CMOS

Horizontal Resolution

HD 1080P 2MPMP

S/N Ratio

More than 50dB

Clock Frequency (MHZ)

NTSC: 28.636

Scanning System

2:1 interlace

Minimum Illumination

0 Lux (with IR LED ON)

Synchronous System

Internal, Negative Sync.

Auto Electronic Shutter

NTSC: 1/60s~1/100,000s

Gamma Characteristic

0.45

IR Project Distance

65feet (with 5x24pcs unit infrared LED)

IR Status

Under 10 Lux by CDS

IR Power On

CDS Auto Control

Video Output

1Vpp

Auto Gain Control

Auto

Dimension (mm)

Ø131 x 93(H)

Weight (g)

500

Power/Current

12VDC(+/-10%)/300mA

Lens

3.6mm Lens

Storage Temperature

-30°C ~ +60°C

package Includes

4CH HD 5MP DVR with 1TB HDD

4 x HD 2MP 4-in-1 MP 1/3" SONY CMOS CCD Metal Housing Camera

2x: 50 feet pre-made cable BNC

2x: 25 feet pre-made cable BNC

1 x  Power Supply For Security Cameras

1 x 1 to 4 Power Splitter Adapter Cable
